LigoDLB 5ax & 5-90ax High-Performance 802.11ax 5GHz Wireless Devices

Product Overview

The LigoDLB ax series adopts 802.11ax technology to deliver high-performance point-to-point and point-to-multipoint wireless connections. The series supports throughput up to 1.5 Gbps, 1024-QAM modulation, and transmit power up to 24 dBm, enabling high-speed, stable long-distance link transmission. Equipped with a dual-core processor, 2.5 Gbps Ethernet port, and support for 160MHz wide channels, the devices ensure outstanding data processing capability and high packet forwarding rate, making them ideal for real-time transmission applications. The rugged IP67-rated enclosure ensures stable operation in all harsh environments.

Key Advantages

Ultra-High Performance: Throughput up to 1500 Mbps, supports 160MHz channel width
Frequency Band: 5.1–5.9 GHz
Strong Anti-Interference: Metal enclosure reduces interference and noise in co-located pole installations, with integrated heat dissipation
Surge Protection: Compliant with IEC 61000-4-5, 6kV line-to-ground, 2kV line-to-line protection
IP67 Protection: Corrosion-resistant metal enclosure for harsh outdoor environments
Dual Ethernet Ports: Gigabit port supports software-controlled PoE output for powering external devices, reducing deployment costs
Remote Management: Built-in 2.4 GHz management radio, supports wireless configuration within 20 meters, improving O&M safety

Model Parameter Comparison

Parameter	LigoDLB 5ax	LigoDLB 5-90ax
Transmission Range	Max/Optimal distance dependent on antenna	Max 6km; Optimal 2km
Antenna Configuration	External antenna N-type connectors	Built-in sector antenna, 17dBi gain
Antenna Beamwidth	–	Horizontal/Vertical 3dB beamwidth 90°; Elevation 8°
Dimensions (without mount)	50mm×140mm×185mm	57mm×144mm×389mm
Weight (with mount)	1.76kg	2.06kg
WLAN Standard	IEEE 802.11a/n/ac/ax
Radio Mode	Dual-chain 2×2 MIMO
Transmit Power	Up to +24dBm (region-dependent)
Max Power Consumption	Up to 15W / 30W (with PoE output enabled)

Software Features

Supports bridging, IPv4 routing, IPv6 routing modes
Static/Dynamic IP configuration, built-in DHCP server; supports NAT, static routing, port forwarding, DMZ
Up to 8 SSIDs per radio; supports data and management VLAN (802.1q) and QnQ
Site survey, Ping/Traceroute, spectrum analysis, Layer3/Layer4 packet analysis
Wireless Security: WPA/WPA2/WPA3 Personal/Enterprise, WACL, client isolation
Management Tools: Web GUI, Infinity Controller, SNMP v1/v2c/v3, system log

Environmental Specifications

Ingress Protection: IP67
Operating Temperature: –40°C (–40°F) ~ +65°C (+149°F)
Operating Humidity: 0~95% (non-condensing)
Surge Protection: Compliant with EN61000-4-5, 10/700μs pulse

Certifications

FCC, CE, UK CA (UK CA certification coming soon)
