PTP5-N/5-23 50-300 km long-range Rapidfire high-bandwidth 802.11AC anti-interference wireless bridge
802.11AC High-Bandwidth Long-Range Wireless Bridge PTP 5-N/5-23 Rapidfire Powerful Wireless Transmission Performance Up to 650 Mbps actual throughput at 35 km Flexible channel bandwidth adjustment: 20MHz/40MHz/80MHz, achieving high spectral efficiency of 7.5 bit/Hz RF design supp...
802.11AC High-Bandwidth Long-Range Wireless Bridge PTP 5-N/5-23 Rapidfire
Powerful Wireless Transmission Performance
- Up to 650 Mbps actual throughput at 35 km
- Flexible channel bandwidth adjustment: 20MHz/40MHz/80MHz, achieving high spectral efficiency of 7.5 bit/Hz
- RF design supports 256QAM modulation, total output power up to 31 dBm, system gain up to 172 dB
Leading Protocol
Adopts industry-leading W-Jet proprietary protocol, designed for complex environments with the following advantages:
- Operates reliably in high-interference environments
- Packet latency as low as 3 ms
- Guarantees high-performance stable transmission
Powerful Hardware Platform
- Built with professional Marvell chipset, equipped with 1.2 GHz dedicated data processing CPU
- 250 KPPS packet processing capability for fast wireless connections
- Dual Gigabit Ethernet ports, supports PoE pass-through
- Redundant port design: one port maintains full function if the other fails, ideal for high-speed video surveillance
- Compliant with 802.3 standards, certified by FCC/IC/CE/RoHS
Professional Design
- 360° rotating mounting bracket for versatile installation and fast deployment
- Two models: PTP 5-23 with built-in dual-polarized antenna, PTP 5-N with 2 N-type connectors
- Rugged die-cast aluminum enclosure, IP-67 ingress protection
- Built-in OLED display and alignment buzzer for easy on-site commissioning
- Integrated antenna with 45° tilt angle for improved installation flexibility
- Removable handle for easy transport
Wireless Configuration Interface
New 2.4G wireless management interface enables wireless connection to various configuration terminals, greatly simplifying troubleshooting. Field tests confirm stable access from 20 meters away when the unit is mounted on top of a 10-story building.
Device Basic Information Example
| Item | Description |
|---|---|
| Product Name | LigoOLB5-158 |
| Serial Number | 0303121100000084 |
| Network Mode | Bridge |
| Wireless Mode | Station (AP NAT) |
| Region | LT |
| Channel | 36/580 MHz |
| Channel Width | 20/40 MHz |
| RF Mode | MIMO 2×2 |
| Antenna Gain | 15 dBi |
Powerful Operating System
Dedicated PTP operating system for efficient network deployment and management:
- Built-in LinkCalcTM link budget calculator, compatible with WNMS for carrier-grade network planning
- Clean, intuitive UI with responsive layout for different screen sizes
- Link setup wizard simplifies PTP configuration, supports single-end setup with automatic master-slave synchronization
- Built-in tools: link test, antenna alignment, spectrum analyzer, field debugging for easy troubleshooting
- Auto-channel selection and automatic transmit power control to optimize link performance in high-interference environments
Wireless Specifications
| Item | Specification |
|---|---|
| Wireless Technology | W-Jet Protocol |
| Wireless Mode | 2×2 MIMO |
| Frequency Range | 4.900–6.100 GHz |
| Channel Width | 5/10/20/40/80 MHz |
| Modulation | OFDM (256-QAM, 64-QAM, 16-QAM, QPSK, BPSK) |
| Data Rate | 866/780/650/585/520/390/260/195/130/65 Mbps |
| Duplex Mode | TDD |
| FEC | BCC, LDPC |
| Antenna (PTP 5-23) | Built-in directional panel MIMO antenna |
| Antenna (PTP 5-N) | MIMO antenna with 2 N-type connectors |
Modulation, Tx Power & Rx Sensitivity Table
| Data Rate (Mbps) | Tx Power (dBm) | Rx Sensitivity (dBm) |
|---|---|---|
| 866 | 25 | -71 |
| 780 | 26 | -73 |
| 650 | 26 | -77 |
| 585 | 27 | -79 |
| 520 | 27 | -80 |
| 390 | 28 | -84 |
| 260 | 29 | -87 |
| 195 | 30 | -92 |
| 130 | 30 | -94 |
| 65 | 31 | -97 |
Physical Characteristics
| Item | PTP 5-23 Rapidfire | PTP 5-N Rapidfire |
|---|---|---|
| Dimensions | W 379mm × H 389mm × D 51mm | W 399mm × H 174mm × D 47mm |
| Weight | 3.9 kg (with mounting kit) | 2.9 kg (with mounting kit) |
| Power Input | PoE 802.3at, 42-57V DC | PoE 802.3at, 42-57V DC |
| Power Consumption | 8.6 W | 8.6 W |
Environmental Specifications
- Operating Temperature: -40°C ~ +65°C
- Operating Humidity: 0 ~ 90% (non-condensing)
Management Features
- Proprietary 2.4 GHz wireless management monitoring
- SNMP v1/2/3, 802.1X, MIB II, WNMS support
- Centralized management GUI, HTTP(S) and WNMS remote management
Software Features
- Simplified configuration process, user-friendly operation
- Master-slave centralized control for unified management of common and dedicated parameters
- Intelligent dynamic polling
- Advanced security for reliable data transmission
- QoS for optimized transmission performance
- Built-in spectrum analyzer for environment monitoring
- OLED display and alignment buzzer for on-site commissioning
- Data backhaul support
Certifications & Protection
- Certifications: FCC/IC/CE/RoHS compliant
- Ingress Protection: IP67
Antenna Specifications
| Item | Specification |
|---|---|
| Frequency Range | 5.1 – 5.9 GHz |
| Gain | 23 dBi / 27 dBi |
| Polarization | Dual-polarized (Vertical / Horizontal) |
| Isolation | Multi-level: 150/210 etc. |
| VSWR | 1.5:1 |
| Horizontal Beamwidth | 6° / 7° |
| Vertical Beamwidth | 9° |
